RavenXTV CDMA Sierra Wireless Cellular Modem
1. Modem name: A unique name for the modem (the 10-digit MDN number
is recommended).
2. Domain: The domain name to be used by the modem (eairlink.com).
3. IP Manager IP Address: The IP or domain name of the dynamic DNS
server which is running IP Manager.
IPMANAGER1: edns2.eairlink.com
IPMANAGER2: eairlink.com
4. IP Manager update interval: How often you want the address sent to IP
Manager. If this is set to zero, the modem will only send an update if the
IP changes (i.e., if the modem is reset or is assigned a different IP). The
value can be set from 0 to 255 minutes.
Restrictions for modem name:
• Must begin with a letter or number
• Can include a hyphen (-)
• Cannot contain spaces
• Must be no longer than 20 characters total
Click the Write icon to save the changes .
Click the Reset icon to restart the modem.
Click the Disconnect icon to terminate communications with the modem.
6. LoggerNet/PC400 Software Setup
The Loggernet “Device Map” is configured from the “Setup” button on the
LoggerNet Toolbar.
Setup has two options, “EZ (simplified)” and “Standard”. Click
on the “View” menu item at the top of the Setup Screen, and
select “Standard” view. NOTE
From the Loggernet Toolbar, click Main | Setup, and configure the Device Map
as described below.
1. Select Add Root | IPPort.
2. Add a datalogger to the IPPort (PakBus dataloggers; e.g., the CR1000,
require a PakBusPort).
15
