Appendix IV

classification According to WMO Guide 1996

Characteristics

CMP 22

CMP 21

CMP 11
CMA 11

CMP 6
CMA 6

High

quality

Good

quality

Moderate

quality

ISO 9060 classification

Secondary

standard

Secondary

standard

Secondary

standard

First class

Secondary

standard

First class

Second

class

Response time (95 percent
response)

5 s

5 s

5 s

18 s

< 15 s

< 30 s

< 60 s

Zero offset:

(a) Response to 200 W/m

2

net thermal radiation
(ventilated)
(b) Response 5 K/h change
in ambient temperature


± 3 W/m

2

± 1 W/m

2


± 7 W/m

2

± 2 W/m

2


± 7 W/m

2

± 2 W/m

2


± 15 W/m

2

± 4 W/m

2

± 7 W/m

2

± 2 W/m

2

± 15 W/m

2

± 4 W/m

2


± 30 W/m

2

± 8 W/m

2

Resolution (smallest detectable
change)

± 1 W/m

2

± 1 W/m

2

± 1 W/m

2

± 1 W/m

2

± 1 W/m

2

± 5 W/m

2

± 10 W/m

2

Stability (change per year,
percentage of full scale)

< 0.5

< 0.5

< 0.5

< 1

± 0.8

± 1.5

± 3.0

Directional response of beam
radiation
(The range of errors caused by
assuming that the normal incidence
responsivity is valid for all directions
when measuring, from any direction,
a beam radiation whose normal
incidence irradiance is 1000 W/m

2

)

± 5 W/m

2

± 10 W/m

2

± 10 W/m

2

± 20 W/m

2

± 10 W/m

2

± 20 W/m

2

± 30 W/m

2

Temperature response (percentage
of maximum due to any change of
ambient temperature within an
interval of 50 K)

± 0.5

-20

0

C-+50

0

C

± 1

-20

0

C-+50

0

C

± 1

-10

0

C-+40

0

C

± 4

-10

0

C-+40

0

C

± 2

± 4

± 8

Non-linearity (percentage deviation
from the responsivity at 500 W/m

2

due to any change of irradiance
within the range 100 to 1000 W/m

2

)

± 0.2

± 0.2

± 0.2

± 1

± 0.5

± 1

± 3

Spectral sensitivity (percentage of
deviation of the product of spectral
absorptance and spectral
transmittance from the corresponding
mean within the range of 0.3 to 3

µm)

± 2

± 5

± 10

Tilt response (percentage deviation
from the responsivity at 0

° tilt,

horizontal, due to change in tilt from
0

° to 90° at 1000 W/m

2

irradiance)

± 0.2

± 0.2

± 0.2

± 1

± 0.5

± 2

± 5

Achievable uncertainty, 95 percent
confidence level

Hourly totals
Daily totals


1 %


2 %


2 %


5 %


3%
2%


8%
5%


20%
10%
