Appendix B. Example Programs
B.1 CRBasic Programs
B.1.1 Example CR1000 Program Using Sequential Mode
This CR1000 program uses the sequential mode, which is the simplest mode
and can be used for most meteorological applications. Although the example is
for the CR1000, other CRBasic dataloggers, such as the CR200(X), CR800,
CR850, CR3000, and CR9000(X) are programmed similarly.
In the example, the CR1000 measures the CS106 once an hour. To do this, the
CR1000 uses a control port to turn on the CS106 one minute before the top of
the hour. On the hour, the datalogger measures the CS106, and then turns the
CS106 off. This example assumes that the jumper is in the default position
(open).
'CR1000
'Declare Variables and Units
Public BattV
Public PTemp_C
Public BP
Public BP_mmHg
Units BattV=Volts
Units PTemp_C=Deg C
Units BP = hPa
Units BP_mmHg=mmHg
'Define Data Tables
DataTable(Table1,True,-1)
DataInterval(0,60,Min,10)
Sample(1,BP_mmHg,FP2)
EndTable
DataTable(Table2,True,-1)
DataInterval(0,1440,Min,10)
Minimum(1,BattV,FP2,False,False)
EndTable
'Main Program
BeginProg
'Main Scan
Scan(5,Sec,1,0)
'Default Datalogger Battery Voltage measurement 'BattV'
Battery(BattV)
'Default Wiring Panel Temperature measurement 'PTemp_C'
PanelTemp(PTemp_C,_60Hz)
'CS106 Barometric Pressure Sensor measurement 'BP_mmHg'
If TimeIntoInterval(59,60,Min) Then PortSet(1,1)
If TimeIntoInterval(0,60,Min) Then
VoltSe(BP,1,mV2500,1,1,0,_60Hz,0.240,500)
BP_mmHg=BP*0.75006
PortSet(1,0)
EndIf
'Call Data Tables and Store Data
CallTable(Table1)
CallTable(Table2)
NextScan
EndProg
B-1
