COM220 Telephone Modem
3.3 LoggerNet Setup
• In the LoggerNet Setup Screen, press Add Root and choose ComPort.
From the ComPort, select Communications, and Add a PhoneBase, a
PhoneRemote, a PakBusPort (if your datalogger is a PakBus datalogger),
and your datalogger.
• Click on the ComPort in your network map, and select the correct
ComPort Connection for your modem.
• Click on the PhoneBase in your network map. Select your PC modem
from the drop-down list or add it using the Edit Modem Database dialog
box. Set the Maximum Baud Rate appropriate for your modem and
datalogger.
• Click on the PhoneModem in your network map. Enter the COM220’s
analog phone number.
• If your datalogger is a PakBus datalogger, click on the datalogger in your
network map. Enter the PakBus Address of your datalogger.
6
