CM106BK Tripod Kit
7.3 CM220 Right Angle Mounting Kit
The CM220 attaches a vertical pipe (1.0 to 1.5 in. OD) to the CM200 series
crossarms or horizontal pipe (1.0 to 1.5 in. OD) as shown in FIGURE 7-3.
FIGURE 7-3. CM220 Right Angle Mounting Kit
CM220
CM220
19
