CM106BK Tripod Kit
5. Tools List (for tripod, mast, enclosures, and
crossarms)
1/2 in. and 7/16 in. open end wrenches
adjustable wrench
Phillips head screw drivers (medium, small)
Straight bit screwdrivers (large, medium)
12 in. torpedo level
side-cut pliers
pencil
tape measure
compass and site declination angle
shovel
sledge hammer (for driving ground rod and stakes)
step ladder
6. Tripod Components
The tripod body is packaged with the lightning rod. The optional guy kit is
packaged separately.
7. Mounting Brackets
Mounting brackets covered in this section have U-bolts that attach to vertical
and/or horizontal pipes with the following ranges of outside diameters:
inches mm Nominal Pipe Size (inches)
1.5 in. U-bolt 1.0 – 1.5 25.4 – 38.1 3/4 – 1
2 in. U-bolt 1.3 – 2.1 33.0 – 53.3 1 – 1 1/2
2 in. U-bolt
with plastic V-block
1.0 – 2.1 25.4 – 53.3 3/4 – 1 1/2
Some of the brackets (e.g. the CM210) include 1.5 in. and 2 in. U-bolts to
extend the range of pipe diameters that the bracket can accommodate. Brackets
with holes for a 1.5 in. U-bolt will accept a user-supplied 1.75 in. U-bolt.
7.1 CM210 Crossarm Mounting Kit
CM200 series crossarms include a CM210 bracket as shown in FIGURE 7-1.
The CM210 can be ordered separately to attach a user-supplied pipe (1.0 to
1.5 in. OD) to a mast or tower leg (1.0 to 2.1 in. OD), or to attach a crossarm to
two tower legs.
