Campbell Scientific 253-L and 257-L (Watermark 200) Soil Matric Potential Sensors User Manual
Page 32
253-L and 257-L Soil Matric Potential Sensors
9: Z=X*F (P37)
1: 6
-- X Loc [ WP_kPa_1 ]
2: 0.0106 F
3: 6
-- Z Loc [ WP_kPa_1 ]
10: Z=F x 10^n (P30)
1: 34.21
F
2: 0
n,
Exponent
of
10
3: 16
Z Loc [ Const_1 ]
11: Z=X-Y (P35)
1: 16
X Loc [ Const_1 ]
2: 1
-- Y Loc [ T107_C_1 ]
3: 16
Z Loc [ Const_1 ]
12: Z=X+Y (P33)
1: 6
-- X Loc [ WP_kPa_1 ]
2: 16
Y Loc [ Const_1 ]
3: 6
-- Z Loc [ WP_kPa_1 ]
13: Z=X*F (P37)
1: 6
-- X Loc [ WP_kPa_1 ]
2: 1.062
F
3: 6
-- Z Loc [ WP_kPa_1 ]
14: Z=X-Y (P35)
1: 6
-- X Loc [ WP_kPa_1 ]
2: 11
-- Y Loc [ kOhms_1 ]
3: 6
-- Z Loc [ WP_kPa_1 ]
15: Z=F x 10^n (P30)
1: 1.306
F
2: -2
n,
Exponent
of
10
3: 17
Z Loc [ Const_2 ]
16: Z=X*Y (P36)
1: 6
-- X Loc [ WP_kPa_1 ]
2: 17
Y Loc [ Const_2 ]
3: 6
-- Z Loc [ WP_kPa_1 ]
17: Z=X/Y (P38)
1: 11
-- X Loc [ kOhms_1 ]
2: 6
-- Y Loc [ WP_kPa_1 ]
3: 6
-- Z Loc [ WP_kPa_1 ]
;End of measurement and processing loop
18: End (P95)
;Turn off multiplexer
19: Do (P86)
1: 51
Set
Port
1
Low
26
