4
Introduction
This document is the User’s Manual for the LCD KVM Drawer from Chatsworth Products, Inc.
(CPI). It guides the user through installation, operation and maintenance of the equipment.
The LCD KVM Drawer is sold individually and in combination with KVM Switches. The table
below lists the CPI Part Numbers for the LCD KVM Drawers and LCD KVM Drawer and Switch
combinations covered by this manual. There is a separate manual for the standalone KVM
switches.
Part Numbers Covered in this Manual
Related
Products
(Standalone)
LCD KVM
Drawer
LCD KVM
Drawer and
Switch
KVM Switch
Description
KVM Switch
Si
n
g
le
Ra
il
37200-111
(US keyboard)
37203-161 Analog, 16 DB15 ports, no IP, no remote 37202-160
37209-261 IP, 16 DB15 ports, 1 IP, no remote 37212-260
37205-361 IP, 16 Cat5/6 ports, 1 IP, 1 remote 37207-360
37205-421 IP, 32 Cat5/6 ports, 2 IP, 1 remote 37207-420
37200-112
(UK keyboard)
37203-162 Analog, 16 DB15 ports, no IP, no remote 37202-160
37209-262 IP, 16 DB15 ports, 1 IP, no remote 37212-260
37205-362 IP, 16 Cat5/6 ports, 1 IP, 1 remote 37207-360
37205-422 IP, 32 Cat5/6 ports, 2 IP, 1 remote 37207-420
Du
a
l Ra
il
37201-111
(US keyboard)
37204-161 Analog, 16 DB15 ports, no IP, no remote 37202-160
37206-361 IP, 16 Cat5/6 ports, 1 IP, 1 remote 37207-360
37206-421 IP, 32 Cat5/6 ports, 2 IP, 1 remote 37207-420
37201-112
(UK keyboard)
37204-162 Analog, 16 DB15 ports, no IP, no remote 37202-160
37206-362 IP, 16 Cat5/6 ports, 1 IP, 1 remote 37207-360
37206-422 IP, 32 Cat5/6 ports, 2 IP, 1 remote 37207-420
LCD KVM Drawer – Product Features
LCD KVM Drawers are 1U high rack-mount consoles that include:
• A 17” LCD flat panel color display
• A US or UK style keyboard with separate number pad
• A built in touchpad with two mouse buttons
• The single rail models have a laptop-style design, fold open when fully extended and are
mounted to a single pair of sliding rails
• On dual rail models, the LCD panel and keyboard tray can be opened or closed separately;
allowing users to leave the LCD panel open while the keyboard tray is stowed
• Includes a combo KVM cable to connect to a single computer or KVM Switch; may also be
ordered with a built-in KVM Switch
