LBL Lighting MO Adjustable Vertical Connector User Manual
Page 3
3
If necessary (depending on design) rotate the Monorail to the
desired angle or horizontal position.
Tighten the two M3 set screws on housing with the 1.5 MM
Allen wrench to the secure the Monorail in place.
If necessary repeat step 10 on page 2 for re-adjusting the
standoff height.
After achieving the desired standoff heights, trim off excess
aircraft cable coming out of the cable grip posts.
M3 SET
SCREW
1.5MM ALLEN
WRENCH
1A
3
4
5
6
4
2C
3
6
4
6
