LBL Lighting LED Illum MO Rail - Manual

Installation Instructions for
Straight LED-Illuminated Monorail
& Fiber Optic Cable
1.1 RAIL-ST-_-LED & LEDMRLFIBER
980MRLRAIL-LED
G P I : ENERAL RODUCT NFORMATION
Standard LED-Illuminated Monorail bends horizontally to a radius
as small as 12". It cannot be bent vertically in the field.
1
Determine the radius of the curve or circle.
On a piece of plywood draw the curved pattern.
Cut out the curved pattern from the plywood.
Make sure that cut out plywood is secured in place.
Hold on edge of the LED-Illuminated Monorail against the
Bend the LED-Illuminated Monorail
CIRCULAR
PLYWOOD
LED-ILLUMINATED
MONORAIL
CIRCULAR
PLYWOOD
Start bending the rest of the LED-Illuminated Monorail against
the circular plywood until the desired curve or circle is
NOTE: Avoid straightening the bent Monorail which
may cause the rails to separate from the insulator.
LED-ILLUMINATED
MONORAIL
LED-Illuminated Monorail
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
1
2
3
4
5
1A 1A
6
1A 1B
