Install the Lamp & Shade
LAMP
Use
Watt Type B13 Medium
MAX 40
Base Torpedo Lamp With Each Socket.
Screw the lamps into the socket.
SOCKET
Align the metal shade holes to the mounting plate side holes.
Replace and tighten the four #8-32 Philip screws to secure the
metal shade in place.
3
#8-32 PHILIPS SCREW
2A
2B
1
2
2
2
2
2
1
1
