LBL Lighting Fiona 18 Flush Mount CF User Manual
Fiona 18 ceiling (compact fluorescent), Install the shade, Install the fixture
Installation Instructions for
Fiona 18 Ceiling (Compact Fluorescent)
1.0
980FIONA18CCF
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
Ceiling
FM700_CF
G
P
I
:
ENERAL
RODUCT NFORMATION
This product can mount to either a 4” square electrical box with a
round plaster ring or an octagon electrical box.
This product is suitable for damp locations.
This instruction shows a typical installation.
Install the Shade
1A
1
Install the shade by aligning the screws on the shade
with the holes on the fixture and secure them together
using the provided knurled nuts.
TOP VIEW
SHADE
FIXTURE
1
1
1
1
1
1
1
Install the Fixture
2A
1
Remove the mounting plate from the fixture base by
unscrewing the two knurled nuts from the two
threaded studs.
MOUNTING PLATE
STUD
KNURLED NUT
1
KNURLED NUT
