LBL Lighting Derby WCF User Manual
Page 2
2
1D
8
9
6
10
6
11
Verify that the mounting plate is level before continuing.
Line up an anchor tip with the center of the mounting
plate hole and push the anchor into the wall up to the
threads.
Screw the anchor in the rest of the way.
Repeat steps 4-6 for the other anchors.
ANCHOR
Slide a #8 screw through a washer and screw it into an
anchor.
Repeat for the other anchors to secure the mounting
plate to the wall.
6
12
1C
Properly place all wire, wire connections, and ballast
inside the electrical box.
Attach the mounting plate to the electrical box using
the two #8-32 screws provided.
6
7
1E
ANCHOR
ANCHOR
SCREW
WASHER
SCREW
WASHER
SCREW
WASHER
#8-32 SCREW
7
7
6
13
