LBL Lighting Derby WD User Manual
Page 3
Slide a #8 screw through a washer and screw it into an
anchor.
Repeat for the other anchors to secure the mounting
plate to the wall.
6
14
1G
SCREW
WASHER
SCREW
WASHER
SCREW
WASHER
6
15
Replace the shade onto the mounting plate and reinstall
the two mounting plate screws. Tighten to secure.
16
1H
MOUNTING
PLATE
SCREW
MOUNTING
PLATE
SCREW
1F
10
11
6
12
6
13
Verify that the mounting plate is level before continuing.
Line up an anchor tip with the center of the mounting
plate hole and push the anchor into the wall up to the
threads.
Screw the anchor in the rest of the way.
Repeat steps 4-6 for the other anchors.
ANCHOR
ANCHOR
ANCHOR
3
