LBL Lighting Derby WD User Manual
Page 2
6
5
DRIVER
2
1D
Properly place all wire, wire nut connections, and the
driver inside the electrical box.
Attach the mounting plate to the electrical box using
the two #8-32 screws provided.
7
8
#8-32 SCREW
8
8
1C
6
4
6
5
Connect the mounting plate ground wire to a suitable
ground in accordance to local electrical codes.
Connect the white driver wire to the neutral power line
wire with a wire nut.
Connect the black driver wire to the hot power line wire
with a wire nut.
6
6
4
1E
6
9
Re-install the LED Plate and secure it tightly with the
two thumb screws.
THUMB SCREW
THUMB SCREW
LED PLATE
