Save these instructions – LBL Lighting Ashland User Manual
Page 2
1C
With the Allen wrench provided, back out (do not fully
remove) the set screw at the base of the fixture.
1D
Properly place the driver, all wires, and wire nut
connections into the electrical box.
Hook the top of the fixture to the top of the mounting
plate and swing the bottom of the fixture toward the
plate until it is flush with the wall.
Tighten the set screw at the bottom of the fixture.
6
