Operation

F232134

12

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

7. If the machine is a coin operated unit, insert

required number of coins to start machine. Refer
to Figure 8.

8. If the machine is a card operated unit, insert and

remove card. Contact the card reader
manufacturer for details.

9. If the machine is interfaced with a central/remote

pay console, make payment and select the
machine. Contact the pay system manufacturer
for more details.

For non-coin models: Press the Start button.
Refer to Figure 9.

Figure 9

10. Add bleach to container 2 when ADD BLEACH

WHEN LIT is illuminated. Refer to Figure 10.

Figure 10

Supply Dispenser

A terminal strip in the input power junction box
provides control signals for an external chemical
supply system on OPL models.

Supply Signal Output Times (OPL models)

Supply Dispenser Flush Times

B157R

1

Detergent

2

Bleach

3

Softener

Figure 8

U136R

B157R

1

2

3

On

Start

Off

WARM

COLD

DELICATE

KNITS

U136R

B158R

Output

Time

1

Prewash Fill

2

When ADD BLEACH

WHEN LIT is illuminated

3

Rinse 3 Fill

4

When ADD BLEACH

WHEN LIT is illuminated

Container

Time

1

Every Fill

2

Wash Fill

3

Rinse 3 Fill

B158R

ON

ADD BLEACH

WHEN LIT
