Adjust the aircraft cables until the fixture is level; feed
the cable into the cable clutch to raise the fixture and
push in on the cable clutch nipple to release the cable
and lower the fixture.
CABLE
CLUTCH
CABLE
CLUTCH
1
5A
Place all wires, wire nut connections, driver, and the
secondary strain relief properly inside the canopy.
Install the canopy onto to crossbar as secure it tightly
with the two thumb nuts.
NOTE:
It is recommended that one person hold the
fixture while the electrician finishes the installation.
12
13
Adjust the Suspension Cables
4D
THUMB NUT
THUMB NUT
