LBL Lighting Vitre Rectangle S User Manual
Vitre suspension (rectangular), Install the mounting plate

1B
1A
1
Install the Mounting Plate
Separate the mounting plate from the canopy by
removing all four mounting plate screws.
MOUNTING
PLATE SCREW
CANOPY
Remove the mounting plate from the canopy.
MOUNTING PLATE
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for damp locations.
This product may be dimmed with a low-voltage electronic dimmer.
Suspension
Vitre Suspension (Rectangular)
1.1
SU830_
Installation Instructions for
980VITRERS
1
2
MOUNTING
PLATE SCREW
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
1C
Secure the mounting plate to the electrical box with the
two #8-32 screws provided.
3
MOUNTING
PLATE
#8-32 SCREW
#8-32 SCREW
