AXIS 225FD - Technical Specifications
42
Technical Specifications
Item Specification
Model AXIS 225FD: Standard lens
AXIS 225FD 22 mm: Tele lens
Image sensor 1/4” Sony Wfine progressive scan RGB CCD
Lens AXIS 225FD: F1.4 varifocal 2.8 – 5.8 mm, DC-iris
AXIS 225FD 22 mm: F1.5 varifocal 9-22 mm, DC-iris
Focus range 0.3m to infinity
Day & night Automatic IR filter removal in low light conditions
Angle of view AXIS 225FD: 36° - 75°
AXIS 225FD 22 mm: 10° - 22°
Camera angle adjustment Pan 360°, tilt 170°, rotation 340°
Minimum illumination AXIS 225FD: Color mode: 1 lux at F1.4, black/white mode: 0.2 lux at F1.4
AXIS 225FD 22 mm: Color mode: 1.5 lux at F1.5, black/white mode: 0.3 lux at F1.5
Video compression Motion JPEG
MPEG-4 Part 2 (ISO/IEC 14496-2), Profiles: ASP and SP
Resolutions 16 resolutions from 640x480 to 160x120 via API,
5 selections via configuration web page
Frame rate Motion JPEG: Up to 30 fps in all resolutions
MPEG-4: Up to 30 fps in all resolutions
Video streaming Simultaneous Motion JPEG and MPEG-4
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG-4)
Image settings Compression levels: 11 (Motion JPEG)/23 (MPEG-4)
Rotation: 90º, 180º, 270º
Configurable color level, brightness, sharpness, contrast, white balance, exposure control,
exposure area, backlight compensation, fine tuning of behavior at low light
Overlay capabilities: time, date, text, privacy mask or image
Shutter time 1/12500 s to 2 s
Security Multiple user access levels with password protection, IP address filtering, HTTPS encryption, IEEE
802.1X network access control, User access log
Users 20 simultaneous users
Unlimited number of users using multicast (MPEG-4)
Alarm and event management Events triggered by video motion detection, tampering detection, temperature limits, external
inputs or according to a schedule
Image upload over FTP, email, and HTTP
Notification over TCP, email, HTTP, and external outputs
9 MB of pre- and post alarm buffer
Connectors Ethernet 10BaseT/100BaseTX, (PoE)
Terminal block for 2 alarm inputs, 1 output, RS-485/422 half duplex port and power
Casing Metal base and polycarbonate transparent cover
Impact-resistant 1000 kg (2200 lbs)
IP66
Tamper-proof mounting
Processors and memory CPU: ETRAX 100LX 32bit
Video processing and compression: ARTPEC-2
Memory: 32 MB RAM, 8 MB Flash
Battery backed up real-time clock
Power • Camera and built-in fan: 9-24V DC, max 5.5W
10-24 V AC, max 8 VA
PoE (IEEE 802.3af) Class 2
• Using the built-in heater: 12V DC, max 20 W
24V AC, max 25 VA
Operating conditions 5 - 50 ºC (41 - 122 ºF)
With heater: -20 - 50 ºC (-4 - 122 ºF)
Humidity 20 - 80% RH (non condensing)
