AXIS 225FD - Event Configuration
21
Event Configuration
An event in the camera is when an Event Type is activated and causes certain actions to be performed. The
event type is the set of parameters (or conditions) that specifies how and when which actions will be performed.
A common event type is when the camera uploads images when an alarm occurs. Many event types use an
Event Server, to e.g. upload images to.
This section describes how to set up event servers and event types, i.e. how to configure the camera to perform
certain actions when events (e.g. alarms) occur.
Definitions
Event Servers
Event Servers are used to receive e.g. uploaded image files and/or notification messages. To set up Event server
connections in your camera, go to Setup > Event Configuration > Event Servers and enter the required
information for the required server type.
For details on each setting, please see the online help available from each web page.
When the setup is complete, the connection can be tested by clicking the Test button (the connection test takes
approximately 10 seconds).
Configuring Event Types
An Event Type describes how and when the camera will
perform certain actions.
Example:
If somebody passes in front of the camera, and an event that
uses motion detection has been configured to act on this, the camera can
e.g. record and save images to an FTP server, and/or send a notification email
to a pre-configured email address with a pre-configured message. Images
can be sent as email attachments.
Event type A set of parameters describing how and when the camera will perform certain actions
Triggered Event - see page 22
An event that is started by some sort of signal, e.g. from an external device, such as a door
switch, motion detection, system event, etc.
Scheduled Event - see page 22 Pre-programmed time period(s) during which an event will run.
Action
That which occurs when the event runs, e.g. the upload of images to an FTP server, email notifi-
cation, etc.
Server type Purpose Information required
FTP Server • Receives uploaded images
• Descriptive name of your choice
• Network address (IP address or host name)
• User name and password (for FTP server)
HTTP Server
• Receives notification messages
• Receives uploaded images
• Descriptive name of your choice
• URL (IP address or host name)
• User name and password (for HTTP server)
TCP Server • Receives notification messages
• Descriptive name of your choice
• Network address (IP address or host name)
• Port number
