Installation Instructions for
Vera Suspension
1.0
980VERAS
Suspension
SU776_2D
G
P
I
:
ENERAL
RODUCT NFORMATION
This product can mount to either a 4” square electrical box with a
round plaster ring or an octagon electrical box.
This product is suitable for damp locations.
This product can be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
1
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
1
Preparing the Canopy
2
1B
1A
Separate the mounting plate from the canopy by
completely unscrewing the strain relief.
1
STRAIN RELIEF
MOUNTING
PLATE
CANOPY
SET SCREW
Loosen
the set screw on the strain relief.
(Do Not Remove)
Install the fixture
NOTE:
Make sure to support the fixture while
adjusting the aircraft cables. An assistant is
recommended to complete the remaining steps.
Feed the aircraft cable(s) through the cable clutch in the
canopy.
Evenly pull the aircraft cable up through the canopy to
raise the fixture to the desired length.
Cut off the excess aircraft cable leaving enough for fine
leveling later.
Feed the power cord from the fixture into the strain
relief and place it back into the canopy.
2
1
2
2
2
3
2
4
2A
CABLE
CLUTCH
AIRCRAFT
CABLE
STRAIN RELIEF
CANOPY
POWER CORD
3
1
SET
SCREW
4
