1i 1j – LBL Lighting Juniper SF User Manual
Page 3
Mount the crossbar to the electrical box with the two #8-32
screws.
#8-32 SCREW
CANOPY
CAP
CABLE GRIP
3
Connect the fixture ground wire to the ground in accordance
with local electrical codes.
Connect the fixture wires properly to power line wires with
wire nuts.
Place all wires and wire nut connections properly inside the
electrical box.
AIRCRAFT CABLE
CAUTION: Cut the access aircraft cable behind the metal
strain relief and make sure that it does not come in contact
with power wires or ground.
Slide the canopy up against the ceiling and secure it by
tightening the cap to cable grip.
1I
1J
17
18
19
1K
20
21
20
21
18
18
17
20
