Operating Instructions FLYTEC 4010 8
When the weather changes fast (e.g. cold fronts), air pressure can change in the course of a
day by up to 5 mbar. This represents a change in altitude of 40 meters!
Another method of calibrating an altimeter is by entering the current QNH. What is the QNH?
In flying circles, a general zero point is needed to enable all aircraft at the same altitude to also
have the same altitude on their altimeters. This joint basis is called the QNH. The QNH is the
current air pressure in hPa (1 hPa = 1 mbar) calculated at sea-level. It is redetermined several
times daily and can be obtained in the flying weather report or from airfields by radio.
Altimeter 1 (ALT 1)
Altimeter 1 displays absolute altitude, i.e. the altitude above sea-level.
Function key is used to change from the displays for altimeter 1, altimeter 2 and the stop-
watch. Pressing and holding down this key will make the instrument go into setting mode.
Altimeter 1 setting mode
As mentioned above, the absolute altitude can
be set in setting mode. The altitude and the
QNH flash on 2 lines. Using the setting keys
and , you can set the altitude and the
QNH simultaneously. If you do not know what
altitude you are currently at, you can set the alti-
tude using the QNH but this method is not as
precise as direct altitude setting. The QNH has
a resolution of 1 mbar which corresponds to an
altitude resolution of approximately 8 meters.
The altitude, however, can be set directly to an
accuracy of 1 meter.
Pressing the setting keys and simulta-
neously will take you from setting mode to opti-
on mode.
Altimeter 1 option mode
In option mode, you can set the unit for ALT 1
(meters or feet) at the first level and, at the
second level, you can set the unit for the QNH
(hPa or in Hg). The indicator for the relevant unit
set flashes in the display.
The pressure sensor can be corrected at the third level (± 50 hPa).
ALT 1
ALT 2
CHRONO
SET-MODE
ALT 1/QNH
OPTION-MODE
ALT1 Unit
m - ft
QNH Unit
hPa - inHg
Sensor
Correction
ALT 1
ALT1
ALT1 4 Sec.
OPTION
OPTION
➀
➁
➂
START - STOP
RESET
START - STOP
RESET
CLEAR ALT 2
CLEAR ALT 2
