10.1. Channels and SIP entity
Many Channels can be assigned as on SIP Entity. Single Channel also can be assign as on SIP
Entity.
Application example:
As the figure below, Channel 1-3 belongs to SIP Entity 1:
Channel 5 belongs to SIP Entity 2:
. and Channel 6-8 belongs to SIP Entity 3:
. When other device under SIP network dial into
, the
phone connect to Channel 1 is ringing. If Channel 1 is under conversation (busy), the line will be
switched to Channel 2, and so on. So Channel 1~3 become a simple Hunting Group. (This feature
needs the support of SIP Proxy Server).
Figure:
VG3310
Internet
SIP IP Phone
Ring
FXS
Busy
Configuration:
WEB page: CHANNEL\
22
