9.2.1. Static IP Mode
The following table shows an example.
IP Address 210.67.96.121
Subnet Mask 255.255.255.248
Default Gateway 210.67.96.120
Web Management
Password 123
Using the information contained in the example above. The procedure is as follows:
1. Connect the gateway to a suitable Power source.
2. Connect a traditional phone set to the “FXS” connector located on the rear panel.
3. When the CPU/ACT light is on, pick up the phone to hear the dialing tone.
4. ##0000
; you should hear three short tones.
5. 010# ; the digit “0” is used to enable “manual” IP mode.
6. 02210*67*96*121# ; IP address.
7. 03255*255*255*248#
; Subnet Mask.
8. 04210*67*96*120# ; Default Gateway.
9. 15123#
; “123” is the web management password.
10. 981# ; Warm-restarts.
11. Hang up the phone. The system should now restart.
You can also use console to configure IP address. But phone number can’t be configured by
console.(Only VG3306/3310/3318)
SIP-RG>enable
SIP-RG#configure
Enter configuration commands, one per line. End with CNTL/Z
SIP-RG(config)#ip state user
SIP-RG(config)#ip address 210.67.96.121 255.255.255.248
System need to restart
SIP-RG(config)#ip default-gateway 210.67.96.120
SIP-RG(config)#exit
SIP-RG#restart
This command resets the system. System will restart operation code agent.
Reset system, [Y]es or [N]o? Yes
9.2.2. DHCP Mode
1. Connect the gateway to a suitable Power source.
