Command Syntax Notes
Draw vertical bar graph ”FE 3D [col][height]
254 61 [col][height]
254 "="[col][height] Draws a vertical bar graph at column
[col] of height [ height]. Height is
measured in pixels (0x00 to 0x14).
User must first use the “v” or “s”
command to initialize characters.
Initialize horizontal bar
graph FE 68
254 104
254 “h” Initialize the user character set to
make horizontal bar graphs.
Draw horizontal bar graph FE 7C [col-
umn][row][dir][length]
254
124 [col-
umn][row][dir][length]
254
[col-
umn][row][dir][length]
Draws a horizontal bar graph start-
ing at column [c] on row [r] with
direction [d](0 is right, 1 is left) of
length [length]. Length is measured
in pixels (0x00 to 0x64 if starting
in column 1). User must first use
the “h” command to initialize char-
acters.
Define custom character FE 4E [c][8 bytes]
254 78 [c][8 bytes]
254 "N" [c][8 bytes] Defines one of 8 custom "user" char-
acters. Character number is [c] be-
tween 0x00 and 0x07.
8.7 Fan and GPO Commands
Table 31: Fan and GPO Commands
Command Syntax Default Notes
General purpose output off FE 56
254 86
254 “V” Off This command
turns OFF any
of the General
Purpose Outputs.
[gpo#] is 1 to 6.
General purpose output on FE 57
254 87
254 “W” Off This command
turns ON any
of the General
Purpose Outputs.
[gpo#] is 1 to 6.
PWM value FE C0
254 192 0 This command
sets one of the
high power GPOs
(GPOs 1-3) into
PWM mode.
Matrix Orbital LK202-24-USB 36
