36
Table 34: General Purpose Output Command Summary
Name Dec Hex ASCII Parameters Response Remembered
General Purpose Output Off 86 56 V Number None Never
General Purpose Output On 87 57 W Number None Never
Set Start Up GPO State 195 C3 ├ Number, State None Always
Table 35: Dallas One-Wire Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Search for a One-Wire Device 200, 2 C8, 02 ╚, ☻ None Data [14] Never
Dallas One-Wire Transaction 200, 1 C8, 01 ╚, ☺ Flags, Send, Receive, Data [] Data [] Never
Table 36: Keypad Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Auto Transmit Key Presses On 65 41 A None None Remember On
Auto Transmit Key Presses Off 79 4F O None None Remember On
Poll Key Press 38 26 & None KeyPress Never
Clear Key Buffer 69 45 E None None Never
Set Debounce Time 85 55 U Time None Remember On
Set Auto Repeat Mode 126 7E ~ Mode None Remember On
Auto Repeat Mode Off 96 60 ` None None Remember On
Assign Keypad Codes 213 D5 ╒ KeyUp [25], KeyDown [25] None Always
Table 37: Display Functions Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Display On 66 42 B Minutes None Remember On
Display Off 70 46 F None None Remember On
Set Brightness 153 99 Ö Brightness None Remember On
Set and Save Brightness 152 98 ÿ Brightness None Always
Set Contrast 80 50 P Contrast None Remember On
Set and Save Contrast 145 91 æ Contrast None Always
Table 38: Data Security Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Set Remember 147 93 ô Switch None Always
Set Data Lock 202, 245, 160 CA, F5, A0 ╩, ⌡, á Level None Remember On
Set and Save Data Lock 203, 245, 160 CB, F5, A0 ╦, ⌡, á Level None Always
Table 39: Miscellaneous Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Write Customer Data 52 34 4 Data [16] None Always
Read Customer Data 53 35 5 None Data [16] Never
Read Version Number 54 36 6 None Version Never
Read Module Type 55 37 7 None Module Never
