Matrix Orbital GLK24064-25 Legacy - Manual (Page 33)

GLK24064-25 rev. 06 33
8.7 File System Commands
In addition to these commands, the mogd.exe program (see section 1.4) is used to download fonts and
graphics to the GLK24064-25.
Table 8-4 File System Commands
Command Syntax Default Notes
Erase file FE B0 [type] [ref]
254 173 [type] [ref] n/a Erases file in memory. Type = 0x01 is font,
type = 0x05 is bitmap. [ref] is reference
number.
Purge memory FE 21 59 21
254 33 89 33 n/a Removes all fonts, font metrics, bitmaps
and settings from memory.
Upload bitmap FE 6E [ref] [size] [data]
254 110 [ref] [size] [data]
254 '~' [ref] [size] [data] n/a Uploads a bitmap to the memory of the
GLK24064-25. See section 6.5.
Upload font FE 24 [ref] [size] [data]
254 36 [ref] [size] [data]
254 '$' [ref] [size] [data] n/a Uploads a font to the memory of the
GLK24064-25. See section 6.4.
8.8 Miscellaneous Commands
Table 8-5 Miscellaneous Commands
Command Syntax Default Notes
Clear display FE 58
254 88
254 'X' n/a Clears screen of text and graphics, places text
cursor at top left.
Set contrast FE 50 [contrast]
254 80 [contrast]
254 'P' [contrast] 0x80
128 Sets display contrast. Compensates for viewing
angle. Contrast is a value between 0 and 255
(hex 0 to FF). Larger = darker.
Set contrast and save FE 91 [contrast]
254 145 [contrast] 0x80
128 Same as "set contrast" but saves [contrast] as
default.
Backlight on FE 42 [minutes]
254 66 [minutes]
254 'B' [minutes] on Backlight will stay on for [minutes]. If [minutes]
= 0 backlight will stay on permanently.
Backlight off FE 46
254 70
254 'F' on Turns off backlight.
General purpose
output on FE 56
254 86
254 'V' off Turns the general purpose output ON.
General purpose
output off FE 57
254 87
254 'W' off Turns the general purpose output OFF.
