Page 24
GLK24064-25 rev. 06
24
The character bitmaps are described in section 6.4.3.
6.4.1 Font File in Table Form
The table below shows the layout of a font file in table form.
File Format (Font)
0xFF
0xFF
X size
Y size
Start
End
O-High
O-Low
Width
O-High
O-Low
Width
O-High
O-Low
Width
O-High
O-Low
Width
O-High
O-Low
Width
O-High
O-Low
Width
O-High
O-Low
Width
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
Data
6.4.2 Uploading the File to the Module
The Upload Font command is used to actually upload the font file. Recall that the syntax for this command
is:
0xFE 0x24 [ref] [file size] [file data]
In this example the file size is 94 bytes (0x5E) and the reference number is '2'. The communications
exchange between the host and the module looks like this:
Host sends
Module sends
0xfe
'$' (command)
'2' (reference)
'2' (echo reference)
0x01 (host confirms echo)
0x5e (low size)
0x5e (echo)
0x01 (host confirms echo)
0x00 (high size)
0x00 (echo)
0x01 (file fits)*
0xFF (first byte of data)
0xFF (echo)
0x01 (host confirms echo)
0xFF (second byte of data)
0xFF (echo)
0x01 (host confirms echo)
0x20 (third byte of data)
0x20 (echo)
0x01 (host confirms echo)
etc
