Model xldp instruction sheet – Ashcroft XLdp - Low Differential Pressure Transmitter User Manual
Page 2
Ashcroft Inc.
250 East Main Street
Stratford, CT 06614
Tel: 203-378-8281
Fax: 203-385-0402
email: [email protected]
www.ashcroft.com
ELECTRICAL CONNECTIONS
(14-22 AWG)
OUT
–
+
VOLTAGE OUTPUT
OUT
+
–
V – V
+
POWER
SUPPLY
KNURLED
BRASS NUT
CURRENT OUTPUT
+
–
POWER
SUPPLY
– +
R
S
XCE Option:
Shield must be connected at instrument only.
General Dimensions
(IN INCHES)
SHIELD
.21 Slot
for #8 or
#10 Screw
3.4
4.6
4.2
3.9
1.7
1.9
1.3
MODEL XLdp
INSTRUCTION SHEET
© 2011 Ashcroft Inc., 250 East Main Street, Stratford, CT 06614, USA • Tel: 203-378-8281, Fax: 203-385-0402 • email: [email protected], www.ashcroft.com.
All specifications subject to change without notice. All sales subject to standard terms and conditions of sale I&M 011-10070 (250-3001) Rev. B 10π/11
