Ashcroft KX - Flush Mount Pressure Transmitter - Manual (Page 2)

© 2011 Ashcroft Inc., 250 East Main Street, Stratford, CT 06614, USA • Tel: 203-378-8281, Fax: 203-385-0402 • email: [email protected], www.ashcroft.com.
All specifications subject to change without notice. All sales subject to standard terms and conditions of sale. I&M011-10156 (250-A152) Rev. A 5/11
MODEL KX THIN FILM
PRESSURE TRANSDUCER
INSTRUCTION SHEET
KX Series Dimensions
GD1 GD2
6.1
5.2
1/2 NPT
CONDUIT
FITTING
O-RING
SEAL
5/16 18 UNC
THREAD
1.032
4.9
4.2
1/2 NPT
(C1)
1.06
.8
GD1 GD2
6.1
5.2
1/2 NPT
CONDUIT
FITTING
O-RING
SEAL
5/16 18 UNC
THREAD
1.032
4.9
4.2
1/2 NPT
(C1)
1.06
.8
KX Series – Electrical Connections
Cable Type C1
Red = + Power
Black = Common
White = Output
DIN Type
PIN-1 = + Power
PIN-2 = Common
PIN-3 = Output
1
2
3
Cable Type C1
Red = + Power
Black = – Power
DIN Type
PIN-1 = + Power
PIN-2 = – Power
1
2
3
+
+ –
POWER
SUPPLY
(+)
(–)
METER
TRANSDUCER
–
V+
V–
PIN 1
PIN 2
4-20 mA
+
+
–
–
POWER
SUPPLY
METER
TRANSDUCER
(Common)
(+ Power)
(+ Output)
PIN 1
PIN 2
PIN 3
3-Wire Voltage
1. Apply 0% Full Scale Pressure.
2. Set the output using the Zero adjustment
potentiometer.
3. Apply 100% Full Scale Pressure.
4. Set the output using the Span adjustment
potentiometer.
5. Repeat steps 1 thru 4 as necessary.
KX Series – Wiring Diagrams KX Series – Recalibration Instructions
Voltage Output Units 1-5, 1-6 Vdc
Current Output Units 4-20mA
