APPENDIX I
AALBORG
7 DFM EEPROM Variables Rev.A3 [12/05/2004]
Gas Independent Variables
INDEX NAME DATA TYPE NOTES
0 BlankEEPROM char[10] Do not modify. Table Revision.
1 SerialNumber char[20] Serial Number
2 ModelNumber char[20] Model Number
3 SoftwareVer char[10] Firmware Version
4 TimeSinceCalHr float Time since last calibration in hours.
5 Options1 uint Misc. Options*
6 Reserved2 char Flow Conditions [0-STD, 1-ACTUAL]
7 AddressRS485 char[3] Two character address for RS485 only
8 DigGasNumber int Current Gas Table Number [0-9]
9 FlowUnits int Current Units of Measure [0-10]
10 AlarmMode char Alarm Mode ['R’- Enabled, 'S’ - Disabled]
11 LowAlarmPFS float Low Flow Alarm Setting [%FS] 0-Disabled
12 HiAlarmPFS float High Flow Alarm Setting [%FS] 0-Disabled
13 AlmDelay uint Flow Alarm Action Delay [0-3600sec] 0-Disabled
14 RelaySetting[0] char Relay #1 Assignment Setting (N, T, H, L, Range)
15 RelaySetting[1] char Relay #2 Assignment Setting (N, T, H, L, Range)
16 TotalMode char Totalizer Mode ['R’- Enabled, 'S’ - Disabled]
17 Total float Totalizer Volume in %*s (updated every 6 min)
18 TotalFlowStart float Start Totalizer at flow [%FS] 0 - Disabled
19 TotalVolStop float Totalizer Action Limit Volume [%*s] 0-Disabled
20 KfactorIndex int Internal K-Factor Index [0-31]**
21 UserDefKfactor float User Defined K-Factor
22 UDUnitKfactor float K-Factor for User Defined Units of Measure
23 UDUnitTimeBase int User Defined Unit Time Base [1, 60, 3600 sec]
24 UDUnitDensity char User Defined Unit Density Flag [Y, N]
25 TPUnits char Temperature/Pressure Units [C (Bar), F (PSI)]
26 FlowOutScaleV float DAC 0-5/0-10 Analog Output Scale for Flow
27 FlowOutScale_mA float DAC 4-20mA Analog Output Scale for Flow
28 FlowOutOffset_mA float DAC 4-20mA Analog Output Offset for Flow
29 TempOutScaleV float DAC 0-5/0-10 Analog Output Scale for Temp.
30 TempOutScale_mA float DAC 4-20mA Analog Output Scale for Temp.
31 TempOutOffset_mA float DAC 4-20mA Analog Output Offset for Temp.
32 PresOutScaleV float DAC 0-5/0-10 Analog Output Scale for Pressure
33 PresOutScale_mA float DAC 4-20mA Analog Output Scale for Pressure
34 PresOutOffset_mA float DAC 4-20mA Analog Output Offset for Pressure
