Table 3-4 shows transmission examples in the buffered mode with STX and ETX included:
Table 3-4. Transmission Data Examples in Buffered Mode With STX and ETX Included
Action Port Powered Insert Reader Data PC Data
PC Sets Buffered Mode B
(0x1B, 0x42)
PC Sets STX S
(0x1B, 0x53)
PC Sets ETX E
(0x1B, 0x45)
Card Inserted 1 (0x02, 0x31, 0x03)
PC Sends Inquiry I
(0x1B, 0x49)
If bad read on insert, reader sends error
status %E?;E?1(0x02,0x25,
0x45,0x3F,0x3D,0x45,0x3F,0x31,0x03)
If good read on insert, sends card data %?;data>?1
Card removed 0 (0x02, 0x30, 0x03)
PC Sends Inquiry I
(0x1B, 0x49)
Sends card data %?;data>?0
PC Sends Inquiry I
(0x1B, 0x49)
Sends card data (data remains in buffer
until a release command has been
received) %?;data>?0
Buffer cleared (released) R
(0x1B, 0x52)
PC Sends Inquiry I
(0x1B, 0x49)
Sends status 0 (0x02, 0x30, 0x03)
