1
SECTION 1. FEATURES AND SPECIFICATIONS
The IntelliStripe 320 is a hybrid, motorized reader that supports both magnetic stripe cards and
smartcard technologies simultaneously. The IntelliStripe 320 Reader can be used in
environments such as self-service kiosks, vending machines, and POS terminals.
The Reader can be used as a smartcard device only, which will provide an intelligent read/write
interface to the user smartcard and can provide read/write access to optional SAMs (Security
Access Modules).
The IntelliStripe 320 can also perform functions related to a “reload station”. In this
environment, financial accounts will be accessed by magnetic-stripe cards or financial cards, and
then the monetary value will subsequently be loaded onto a secondary smartcard.
CONFIGURATIONS
Part
Number
Description
16050307 IntelliStripe 320, 3Trk, RS-232/USB with C Bezel, Stripe down
16050308 IntelliStripe 320, 3Trk, RS-232/USB with D Bezel
16050309 IntelliStripe 320, 3Trk, RS-232/USB with C Bezel, Stripe down, Contactless Ready*
16050310 IntelliStripe 320, 3Trk, RS-232/USB with D Bezel, Contactless Ready
16050314 IntelliStripe 320, 3Trk, RS-232/USB with A Bezel
16050315 IntelliStripe 320, 3Trk, RS-232/USB with A Bezel, Contactless Ready
16050316 IntelliStripe 320, 3Trk, RS-232/USB with C-Bezel, Stripe down, Contactless Full*
16050317 IntelliStripe 320, 3Trk, RS-232/USB with D-Bezel, Contactless Full
16050319 IntelliStripe 320, 3Trk, RS-232/USB with A-Bezel (Special)
* Contactless Ready implies that the contactless module can be installed at a later date
Contactless Full indicates that the contactless module is included with the reader
