IntelliStripe 320 Motorized Reader
2
STANDARD FEATURES
Standard features of the IntelliStripe 320 are as follows:
•
Motorized transport
•
RS232 and USB interfaces
•
On board intelligence for transporting large blocks of data using a defined protocol and
command set
•
Flash upgradeable
•
8 Smart Card Contacts for reading ISO contact locations
•
On board SAM (Security Access Module)
•
Supports all magnetic stripe 3-track combinations
•
Front Card Gate prevents coins, dust, moisture, and debris, from entering the unit – gate
resists opening except when ISO-size card enters the unit
•
Power failure card ejection system (requires optional external capacitor)
•
Test LED
•
External Bezel LED
•
Multiple communication protocols (MCP and simple ASCII)
•
Optional support for Contactless Smart Cards
•
Non-volatile property configuration
ACCESSORIES
Other part numbers that may be shipped with the unit are as follows:
Part
Number
Description
16051408 RS232 / Power cable
−6 foot IntelliStripe 320 host port to 9 pin D female RS232 and
2.5mm power jack
16051433 USB-A to USB mini-B cable, 6 foot, gray
30037472
or
99510015
IntelliStripe Picture Demo Software (CD or on line at www.MagTek.com)
30037473
or
99510016
MCP Drivers (CD or on line at www.MagTek.com)
51300004 OTI Contactless communication module (mounts on “Contactless Ready” models
51300005
OTI Contactless antenna with LEDs (must be mounted away from IntelliStripe 65
bezel)
51300006 OTI coax antenna cable – 30cm (does not support LEDs)
51300007 OTI ribbon antenna cable – 19cm (supports LEDs)
51300012 Same as 51300004 but with SAM socket
64300080 Power Supply–Autoranging 100V-250V, regulated, 12VDC, 1.5A, 2.5mm plug
64300104 Power Supply–Autoranging 100V-250V, regulated, 12VDC, 2.5A, 2.5mm plug –
required if Contactless Smart Card option is included
71100001 A/C Adapter/Power Cord for North American applications
