Section 1. Features and Specifications
7
MECHANICAL
Chassis Mounting Options
With “A” and “C” Bezel, screws mounted from above unit,
magstripe down and to the right
With “A” Bezel only, screws mounted from above or under unit.
With “D” Bezel, screws mounted from above or under unit.
Dimensions (Core Chassis)
Length (with “A” Bezel)
Width (with “A” Bezel)
Height (with “A” Bezel)
Length (with “C” Bezel)
Width (with “C” Bezel)
Height (with “C” Bezel)
Length (with “D” Bezel)
Width (with “D” Bezel)
Height (with “D” Bezel)
Cable Length (16051408)
A/C Adapter Cable Length
(71100001)
5.85” (148.59 mm) (includes flex cable connector overhang)
3.26” (82.91 mm)
2.17” (55.12 mm)
6.83” (173.48 mm)
3.26” (82.91 mm)
2.17” (55.12 mm)
6.26” (159.00 mm)
4.00” (101.60 mm)
2.17” (55.12 mm)
6’
± 0.1’ (1.83 m ±0.03 m)
6.25’ (1.91 m)
Weight:
Reader with “A” Bezel
“C” Bezel w/screws
“D” Bezel w/screws
Reader Cable
A/C Adapter Regulator with
Power Cord
15.40oz. (436.58 g.)
1.40 oz. (39.69 g.)
1.08 oz. (30.58 g.)
4.15 oz. (117.76 g.)
11.87 oz. (336.60 g.)
ENVIRONMENTAL
Temperature
Operating
Storage
32
o
F to 122
o
F (0
o
C to 50
o
C)
-4
o
F to 158
o
F (-20
o
C to 70
o
C)
Humidity
Operating
Storage
10% to 90% noncondensing
10% to 90% noncondensing
Altitude
Operating
Storage
0-10,000 ft. (0-3,048 m.)
0-50,000 ft. (0-15,240 m.)
