EN - English - I
nstruc
tions manual
2 • MNVKDBH06789_0813_EN
Check the contents to make sure they correspond
with the list of materials as below:
DBH06:
Aluminium bracket •
1 housing equipment: •
2 screws M5x30mm •
1 hex key •
DBH07:
Aluminium bracket •
1 housing equipment: •
2 screws M5x30mm •
1 hex key •
DBH08:
Aluminium bracket •
1 housing equipment: •
4 screws M5x30mm •
1 hex key •
DBH09:
Aluminium closing flange •
Steel base •
4 nuts M8 •
4 toothed washers for M8 screws •
Safely disposing of 5.2
packaging material
The packaging material can all be recycled.
The installer technician will be responsible for
separating the material for disposal, and in
any case for compliance with the legislation
in force where the device is to be used.
Bear in mind that if the material has to be returned
due to a fault, using the original packaging
for its transport is strongly recommended.
Identification 4
Product description 4.1
and type designation
Attachment supports for DBH18, make it possible
to install the housing in any position as desired,
allowing installation in places where access is difficult.
DBH06 • - Support for wall installation.
DBH07 • - Support for installation
on parapet or ceiling.
DBH08
• - Accessory spacer for support DBH07,
making it possible to install the housing lower
down, if DBH07 is used as a ceiling support, or
to install the housing at a distance from the
parapet, if DBH07 is used as a parapet support.
DBH09
• - Accessory for the DBH07 base, so that the
housing can be rotated if installed on a parapet,
making installation and maintenance easier.
Preparing the 5
product for use
Any change that is not expressly h
approved by the manufacturer
will invalidate the guarantee.
Contents and unpacking 5.1
When the product is delivered, make sure that
the package is intact and that there are no
signs that it has been dropped or scratched.
If there are obvious signs of damage,
contact the supplier immediately.
Keep the packaging in case you need
to send the product for repairs.
