Installation
7
3. Backstop / Torque Arms
Removal of backstops or torque arms may cause unexpected machine movement. Remove or block all external loads before
servicing the unit. Failure to observe these precautions could result in bodily injury.
Bolt motor in place and install driver and driven sheaves.
Check for alignment.
Attach turnbuckle and turnbuckle mounting bracket.
Install V-belts, tighten turnbuckle and lock in place with lock nuts.
Add oil to reducer. Recommended oil is generally indicated on the reducer name tag.
Install V-belt drive guard.
Connect electric motor.
