CEMA STANDARD NO: 352-2012
SCREW CONVEYOR COMPONENTS
Item Descripton
1 Screw
2 Screw with Bare Pipe at Discharge
3 Coupling Bolts (Not Shown)
4 Coupling Shaft
5 Hanger with Bearing
6 Tail End Trough End
7 Trough End for Screw Conveyor Drive
8 Trough End for Screw Conveyor Drive
9 Trough with Discharge Spout
10 Seal
11 Bearing
12 Tail Shaft
13 Flanged Cover
14 Flanged Cover with Inlet
15 Buttstrap
16
Screw Conveyor Drive Unit with Motor Mount,
V-Belt Drive, and Guard
Bill of Materials
7.
