iii - DriMaster HiFlo Upholstery Tool Owner’s Manual
List of Figures
Figure 1-1. DM III Shown with Hide-A-Hose Attached.................................................1-1
Figure 2-1. Attach Optional Accessory Handle to the DM III .......................................2-2
Figure 2-2. Attach Solution Hose and Adjust Solution Control Knob ...........................2-3
Figure 2-3. Turning Knob to “HiFlo” Position Forms
Sheet of Solution Across Bar Jet ..............................................................2-4
Figure 3-1. Clean Bar Jet Assembly with Feeler Gauge..............................................3-1
Figure 3-3. Remove Filter Cartridge and Orifice Plate ................................................3-2
Figure 3-2. Disassemble Quick Connect .....................................................................3-2
Figure 3-4. Remove Four 4-40 Screws (Circled) from Nose of Tool ............................3-4
Figure 3-5. Re-install Nose ..........................................................................................3-4
Figure 4-1. Adhesive/Sealant Material Reference .......................................................4-2
Figure 4-2. HiFlo Handpiece Assembly .......................................................................4-3
Figure 4-3. Knob Assembly .........................................................................................4-5
Figure 4-4. Hide-a-Hose Assembly..............................................................................4-6
Figure 4-5. Bar Jet Assembly ......................................................................................4-7
Figure 4-6. Handle Accessory Assembly .....................................................................4-8
