Tool Maintenance: 3-2
CLEANING THE FILTER CARTRIDGE
AND ORIFICE PLATE
1. Disassemble the Hide-a-Hose
quick connect to gain access to the
filter cartridge and orifice plate (see
Figure 3-2 and Figure 3-3).
2. Remove the filter cartridge and
orifice plate, place them in a cup
full of white vinegar and soak for
30 minutes.
Figure 3-2. Disassemble Quick Connect
Figure 3-3. Remove Filter Cartridge and Orifice Plate
Orifice Plate
Filter Cartridge
