3-1: Tool Maintenance
3 - Tool Maintenance
CLEANING BAR JET ASSEMBLY
The bar jet assembly needs to be
cleaned with a 0.015” feeler gauge.
1. Slide the feeler gauge into the
small slot (see Figure 3-1).
2. Gently slide the gauge back and
forth to clear any debris from the
opening
.
Use only a feeler gauge to clean
the slot in the bar jet. Use of any
other implement (paper clip, knife
blade) may damage the opening
and seriously reduce the cleaning
effectiveness of the upholstery
tool.
HydraMaster recommends you clean the filter cartridge and orifice plate on a
periodic basis to eliminate hard water deposit buildup. Both components are
conveniently located in the Hide-a-Hose solution quick connect (see Figure 3-2).
See page 3-4 for additional cleaning information.
Figure 3-1. Clean Bar Jet Assembly with
Feeler Gauge
