Operating Instructions: 2-2
OPTIONAL ACCESSORY HANDLE ASSEMBLY (P/N 000-061-144)
The DriMaster III HiFlo tool can be equipped with an optional accessory handle (purchased
separately) to increase comfort and control during difficult or extended repetitious use of
the upholstery tool.
1. Attach the left and right handles (items 3 and 4 - see Figure 2-1) to the DM III.
2. The shorter screws, nuts, and washers (items 2, 5 and 6) are used on the upper
handle.
3. The longer screws, nuts and washers (items 1, 5 and 6) are used to connect the
assembled handle to the tool body.
Figure 2-1. Attach Optional Accessory Handle to the DM III
