Phottix Atlas II - Manual (Page 8)

8
One Phottix Atlas II can be used to trigger two
studio strobes or two flashes. Both flashes or
studio strobes must be of the same brand,
model, and voltage. DO NOT USE DIFFERENT
FLASHES! Flashes have different trigger volt-
ages – use the same make and model. Phottix
is not responsible for damage resulting from
improper use.
1. Turn off the camera, flash/strobe, and the
Connecting two flashes /
studio lights
Phottix Atlas II transceiver.
2. Connect compatible cables to the Atlas II
Flash in/out port and Flash out port.
3. Connect the cables to two flashes or strobes.
4. Set the Transmit / Receive Mode Switch on
the Atlas II to Rx (receive mode).
5. Turn on the flash/strobe, Phottix Atlas II and
camera.
6. Set the flash to Manual mode.
* It is not unusual for the flash to discharge
once after turning on the Phottix Atlas II.
6. Turn on the camera, Phottix Atlas II and
flash.
7. Set the camera and flash to Manual mode.
* It is not unusual for the flash to discharge
once after turning on the Phottix Atlas II.
