7
4. Settings
4.1 Transceiver Settings
Complete the necessary transceiver (TS-590S) settings before using the USB audio
function. (Refer to the user manual for how to use the TS-590S.)
4.1.1 Setting Up an Audio Input Route from the Rear Terminal
On the rear terminal there are two types of audio input routes – the ACC2 connector
route and the USB connector route for using the USB audio function. Make the
following menu settings to transmit audio input from the USB connector.
Menu No. Function Set value
63 Audio input line selection for data
communications
USB
The default setting is ACC2.
4.1.2 Audio I/O Level Settings
Use the following menu to adjust audio transmission input levels from the PC, and
receive audio output levels to the PC.
Menu No. Function Setting range
64 Audio level of USB input for data
communications
0 to 9
65 Audio level of USB output for data
communications
0 to 9
The default value for all settings is 4.
4.1.3 Mixed Beep Setting to External Audio Outputs
With the TS-590S default mode, only received audio signals that do not include beeps
or side tones are output as audio signals from the ACC2 connector and the USB
connector as USB audio signals.
Make the following menu settings to output the same audio as the audio output from
the wireless speaker, including beeps and side tones, externally.
Menu No. Function Set value
68 Mixing beep tones for ACC2/USB audio
outputs
ON
The default setting is OFF.
