8
1.3 Technical description
1.3.1 Measurements
See figure 4
All dimensions in mm, rounded up to the nearest 5 mm.
Size BFM 30 BFM 50 BFM 80
A 1995 1995 2020
B 1795 1795 1820
C 600 600 600
D 520 520 525
E 600 600 590
F 1640 1640 1655
G 1360 1360 1360
H 630 630 625
K 710 710 710
L 1000 1000 1000
M 755 755 755
N 80/125 100/150 130/200
1 Cold water inletRP1½
2 Hot water outletRP 1½
3 Gas valve RP ¾
4 Drain valve ¾"-14 NPT
5 T&P-connection (temperature- and pressure valve) 1"-14 NPT
