46 K-531
Specifications
Amplifier
Effective output power during STEREO operation 40 W + 40 W, RMS (1 kHz, 10% T.H.D., 4 Ω)
Total harmonic distortion 0.03% (1 kHz, 1 W, 4 Ω)
Tone control
characteristics BASS (TURN OVER 100 Hz) ±4.0 dB (at 100 Hz)
(TURN OVER 150 Hz) ±6.6 dB (at 100 Hz)
(TURN OVER 200 Hz) ±7.5 dB (at 100 Hz)
MID (TURN OVER 1 kHz) ±8.0 dB (at 1 kHz)
(TURN OVER 2 kHz) ±8.0 dB (at 2 kHz)
(TURN OVER 3 kHz) ±8.0 dB (at 3 kHz)
TREBLE (TURN OVER 5 kHz) ±7.6 dB (at 10 kHz)
(TURN OVER 7 kHz) ±6.7 dB (at 10 kHz)
(TURN OVER 10 kHz) ±4.0 dB (at 10 kHz)
D-Bass (+10) +15.9 dB (60 Hz, Vol. 60)
Input terminals (Sensitivity/Impedance) AUX PLAY IN 500 mV / 47 kΩ
AUDIO IN 250 mV / 47 kΩ
Output terminals (Level/Impedance) SUB WOOFER PRE OUT 2 V / 160 Ω
AUX REC OUT 500 mV / 160 Ω
Digital unit
Sampling frequencies 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Supreme EX (CD, D-IN, iPod, USB)
Playable
frequencies
1 Hz to 24 kHz
Input terminals (Sensitivity/Wave length) Optical –15 dBm to –24 dBm, 660 nm ±30 nm
Output terminals (Level/Wave length) Optical –21 dBm to –15 dBm, 660 nm
USB
Usable USB device USB Mass storage class device
Interface USB2.0 (Full speed) USB1.1 compatible
File system FAT 16/FAT 32
Output DC 5 V 500 mA
iPod/iPhone
Output DC 5 V 1 A
Tuner
FM tuner Reception frequency range 87.5 MHz to 108 MHz
Antenna impedance 75 Ω unbalanced
AM tuner Reception frequency range 531 kHz to 1,602 kHz
