48
Actiontec Wireless-Ready DSL Gateway
Automatic Water Meter
If an automatic water meter and Qwest DSL share a phone line, a DSL phone filter
must be installed on the water meter. If needed, contact the water company for
assistance in connecting the phone filter.
PBX or Key System
To share Qwest DSL with telephone line in an office PBX or key system:
1. In the building’s phone closet, splice (into two lines) the telephone line on
which Qwest DSL is installed.
2. On one of the spliced lines, connect the Gateway. The Gateway should be con-
nected as close as possible to the telephone network to assure a strong signal.
3. Connect the Gateway to a computer or LAN hub via Ethernet cable.
4. On the other spliced line, install the DSL phone filter, then wire normally
through the PBX or key system unit to the telephone.
