Actiontec electronic Wireless-Ready - Manual (Page 34)

31
Chapter 6 Advanced Configuration
The beginning and ending IP addresses define the IP address range of the
Gateway. If the default values are left intact, the Gateway supplies a unique IP
address between 192.168.0.2 and 192.168.0.254 to each computer on the net-
work. Note that the first three groups of numbers of the addresses are identical;
this means they are on the same subnet. The
IP address of the Gateway must be
on the same subnet as the IP address range it generates. For instance, if the
Gateway’s IP address is changed to 111.33.222.1, set the beginning IP address to
111.33.222.2, and the ending IP address to 111.33.222.254.
DNS Server 1 - the primary DNS server provided by the ISP . If the ISP
provided DNS server information, enter it here. If not, leave the
text box intact.
DNS Server 2 - the secondary DNS provided by the ISP . If the ISP pro-
vided secondary DNS server information, enter it here. If not,
leave the text box intact.
Services Blocking
Selecting Services Blocking in the “Advanced Configuration” screen generates the
“Services Blocking” screen.
To modify Internet privileges (Web, FTP , Newsgroups, etc.) for the computers on
the network:
1. Enter the computer’s IP address in the Enter IP Address: text box.
2. At the bottom of the screen, select the Internet service(s) to be blocked.
3. Click Add to enter the computer’s IP address in the “Blocked IP Address List”
text box.
4. To remove blocked services, select the computer’s IP address in the “Blocked
IP Address List” text box and click Remove.
